If you want to...
specify the font for the heading text
display the title of the schedule
display the scheduled fields as column titles
insert a blank row before the data rows
specify the font for the body text
Formatting Units and Number Fields in a Schedule
1 In the Project Browser, right-click the schedule name, and select Properties.
2 In the Element Properties dialog, for Formatting, click Edit.
3 Select a length (includes height fields), area, volume, angle, or Number field from the list.
NOTE A Number field is a project parameter or calculated value that was created as a Number type.
When you create a calculated value on the Fields tab of the Schedule Properties dialog, you see the
Calculated Value dialog, where you can select the type. The following image shows this dialog with
the Number type selected.
4 Click Field Format.
The Format dialog appears. The Use project settings option is selected by default. This means
that values display according to the units setting in the project.
5 Clear the Use project settings option.
6 If you selected a length, area, volume, or angle field:
a For Units, select an appropriate unit.
then select...
this option, but the Grid lines option is still selected, the grid
line style is used as the border style.
a font from the list, enter a font size, and select bold or italic
attributes.
Title. To create a different underscore line style, select Under-
line and then select the line style from the list.
Column headers. To create a different underscore line style,
select Underline, and then select the line style from the list.
Blank row before data. This option affects both the schedule
segment on the sheet and the schedule view.
a font from the list, enter a font size, and select bold or italic
attributes.
Specifying Schedule Properties | 137
