Roof Instance Properties

Name
Constraints
Base Level
Room Bounding
Related to Mass
Base Offset From Level
Cutoff Level
Cutoff Offset
Extrusion start
Extrusion end
Reference Level
Level Offset
Construction
Fascia Depth
Rafter Cut
Rafter or Truss
Description
Sets the level for the footprint or extruded roof.
If selected, it means the roof is part of a room boundary. If not selected, it means
the roof is not part of a room boundary. This property is read-only before creating
a roof. After you draw the roof, you can select it and then modify this property.
Indicates the element was created from a mass element. This is a read-only value.
Sets the height of the roof above or below the level where it is being sketched. This
property is enabled only when creating a roof by footprint.
Specifies a level above which all footprint roof geometry will be not shown. Roofs
cut in this manner can be combined with another roof to form Dutch Hip, Mansard,
or other roof styles.
Height of the cutoff above or below the level specified in Up to Level.
Sets the start point of the extrusion. For example, if you pick the outer edge of the
wall during creation of the extrusion, the start point starts the extrusion to some
point traveling out from the outer edge of the wall. This parameter is only enabled
for extruded roofs.
Sets the end point of the extrusion. For example, if you pick the outer edge of the
wall during creation of the extrusion, the end point ends the extrusion at some point
out from the outer edge of the wall. This parameter is only enabled for extruded
roofs.
The reference level for the roof. The default is the highest level in the project. This
parameter is only enabled for extruded roofs.
Raises or lowers the roof from the reference level. This parameter is only enabled
for extruded roofs.
The length of the lines defining the fascia.
Defines the rafter cut on an eave. See
Two-Cut Square Eave on page 618.
This property is a switch for the Plate Offset from Base property. If you choose Rafter,
the Plate Offset from Base is measured from the inside of the wall. If you choose
Truss, the Plate Offset from Base is measured from the outside of the wall. To see
Creating a Plumb Cut, Two-Cut Plumb, or
Roof Properties | 637
