Modifying a View Title Type

1 Open the view title type for editing, using one of the following methods:
2 Modify the view title type as desired.
3 Click File
4 Load the view title type into a project.

Loading a View Title Type into a Project

You can load a view title type into a project as follows:
When creating or modifying a view title type. After saving changes to the view title type in the Family
Editor, click Load into Projects on the Design Bar. Select the open projects into which you want to load
the view title type, and click OK.
Using the File menu in a project. The view title type is then available when you edit viewport types within
the project. Use the following procedure.
To load a view title type using the File menu
1 Open a Revit project.
2 Click File menu
3 In the Open dialog, navigate to the location of the view title type file.
4 Select the view title type file, and click Open.
Revit Architecture loads the view title type into the project. In the Project Browser, the view title type displays
under Families
1000 | Chapter 15 Preparing Construction Documents
Open a project that contains sheets that use the view title type (or a project into which you
have loaded the view title type). In the Project Browser, expand Families
Symbols. Right-click the name of the view title type to modify, and click Edit.
In the Revit window, click File menu
(RFA) file. Select the file, and click Open.
The Family Editor opens, displaying the view title type in the drawing area.
To rotate text or a label in a view title, select the text or label, and drag the rotation controls.
To change text in the view title, double-click the text, and edit it.
To change the type of text used to display a label, select the label in the drawing area. In the
Type Selector, select another label type, or click
parameters for the current label type.
Save, and click Save.
See Loading a View Title Type into a Project
Load From Library
The default view title types contain View Title in their file names. They reside in the following
default location:
C:\Documents and Settings\All Users\Application Data\Autodesk\<product and
release>\<Imperial or Metric Library>\Annotations
Annotation Symbols.
Open. Navigate to the location of the view title type
and then click Edit/New to edit text
on page 1000.
Load Family.
Annotation
