If the desired window type does not appear in the list, you can load additional window types.
On the Options Bar, click Load, and navigate to the family file that contains the desired window
type.

Modifying the Window Position

1 In a plan view, select the window.
2 Right-click to open the shortcut menu.
3 Choose from the following commands:
Flip Hand: flips the window horizontally. This option is available only if the particular
window family was created with horizontal controls.
Flip Facing: flips the window vertically. This option is available only if the particular window
family was created with vertical controls.
Also see Rehosting on page 747 for information about moving a window from one host to another.

Window Properties

Parameter names, values, and descriptions for windows. Values are modifiable.
NOTE This topic contains information on the common window properties. However, properties can vary among
the different window types (families).
Modifying Window Properties
1 From a plan view, select the window and click
2 In the Element Properties dialog, edit window instance parameters.
See Window Instance Properties
3 Click Edit/New to edit window type parameters.
See Window Type Properties
NOTE Changes made to type parameters affect all windows of this type in the project. You can click
Duplicate to create a new window type.
4 Click OK.
Window Type Properties
Name
Construction
Wall Closure
on page 741.
on page 739.
Description
This parameter sets the layer wrapping around the window. It overrides any settings
in the host.
.
