When you edit a group externally, the group opens as a Revit project file (RVT) or a Revit family file (RFA),
depending on the environment from which you open it.

Adding or Removing Elements in a Group

1 In the drawing area, select the group to modify. If the group to modify is nested, press TAB until
2 On the Options Bar, click Edit Group.
3 On the group editor toolbar, click
4 Select the elements to add or remove from the group.
5 When you are finished, click

Excluding Elements from a Group Instance

Excluding elements from a group instance may be useful when, for example, you place a hotel unit group
defined with 4 bounding walls adjacent to a similar unit, and the walls overlap. You can exclude the
overlapping wall from the group instance. If the excluded wall is hosting any elements (for example, a wall
hosted tub or a door), Revit Architecture attempts to rehost those elements on the remaining wall.
You can exclude an element using any of the following methods:
Exclude an element from a group instance. The element remains in the group but is not visible in the
project view for that group instance. If the excluded element is hosting any elements, Revit Architecture
attempts to rehost those elements.
Move an element from a group instance to the project view. The element is visible in the project view,
and can be edited from the project view. The element is also excluded from the group instance.
When elements are excluded and are not visible in the project view for a group instance, they are not included
in schedules.
Excluded elements can be restored to their group instances.
To exclude an element from a group instance:
1 In the drawing area, place the cursor over the group element to exclude.
2 Press TAB to highlight the element, and then click to select it.
3 Click the icon (
290 | Chapter 7 Editing Elements
the group is highlighted, and click to select it.
elements from the group.
NOTE If you add a view-specific element to a model group (for example, a window tag), the
view-specific element is placed in the project view and not in the model group.
) to exclude the element, or click Edit menu
NOTE You can also use the following keyboard shortcuts: DELETE or CTRL-X.
to add elements to the group, or click
.
to remove
Group Exclude Member.
