To create a volume analysis schedule
1 Create mass floors.
See Creating Mass Floors
2 Click View menu
Schedule/Quantities.
3 In the New Schedule dialog, do the following:
a For Category, click Mass Floor.
b For Name, specify the schedule name.
c Select Schedule building components.
d Click OK.
4 On the Fields tab of the Schedule Properties dialog, for Scheduled fields (in order), add the
following fields:
Usage
Level
Mass: Type
Floor Volume
5 Click OK twice.
6 In the schedule, assign a usage to each mass floor.
Enter text in the Usage column for each level. After entering initial values, for the remaining
rows you can click in the field to select values from a list.
Next, sort and subtotal the schedule by usage, as follows.
7 Open the view properties for the schedule. (Right-click in the drawing area for the schedule,
and click View Properties.)
8 For Sorting/Grouping, click Edit.
9 On the Sorting/Grouping tab of the Schedule Properties dialog, do the following:
a For Sort by, select the following:
Usage
Ascending
Footer
Title and totals
Blank line
b For Then by, select both Level and Ascending.
c At the bottom of the dialog, select the following:
Grand totals
Title and totals
Itemize every instance
10 Click the Formatting tab, and do the following:
a Under Fields, select Floor Volume.
on page 525.
New Schedule/Quantities, or on the View tab of the Design Bar, click
Examples of Conceptual Design Analysis | 539
