4 Click Apply to view your changes. Click OK to exit the Edit Color Scheme dialog.
To modify the graphic appearance of legend swatches
1 In the drawing area, select the color scheme legend.
2 On the Options Bar, click Edit Color Scheme.
3 In the Edit Color Scheme dialog, change the color and fill patterns as necessary for the desired
4 Click Apply to view your changes. Click OK to exit the Edit Color Scheme dialog.
To change the legend title
1 In the drawing area, select the color scheme legend.
2 On the Options Bar, click Edit Color Scheme.
3 Edit the text for Title.
4 Click Apply to view your changes. Click OK to exit the Edit Color Scheme dialog.
To show or hide the legend title
1 In the drawing area, select the color scheme legend.
2 Click
3 In the Element Properties dialog, click Edit/New.
4 In the Type Properties dialog, select or clear the Show Title parameter value.
5 Click OK twice.

Color Scheme Legend Properties

Name
Graphics
Swatch Width
Swatch Height
Values Displayed
964 | Chapter 14 Rooms and Areas
NOTE When you modify the order of items, all project views that use the color scheme are affected.
values.
NOTE When you modify the graphic appearance of legend swatches, all project views that use the
color scheme are affected.
NOTE When you modify the legend title for a color scheme, all project views that use the color
scheme are affected.
.
NOTE Changes made to this type parameter affect all color scheme legends of this type in the project.
Description
Controls the width of the swatches.
Controls the height of the swatches.
Filters the display of values in a view. By view shows only the values in the current view. All shows all
values present in the color scheme.
