12 Under Moment Symbols, select a symbol for Cantilever connection.
13 Click OK.

Annotation Styles

You can create or modify leader arrowhead, text note, dimension, and loaded tag styles in a project.

Specifying Arrowhead Styles

1 Click Settings menu
2 In the Type Properties dialog, select the arrowhead type you want to work with from the Type
3 If desired, click Rename to rename the type, or click Duplicate to create a new arrowhead type.
4 Specify the properties for the display of leader arrowheads. See
5 Click OK.

Specifying Text Note Styles

1 Click Settings menu
2 In the Type Properties dialog, select the text properties you want to work with from the Type
3 If desired, click Rename to rename the type, or click Duplicate to create a new text type.
4 Specify the properties for the display of text notes.
5 Click OK.

Specifying Dimension Styles

You can specify the style of linear, angular, or radial dimensions.
1 Click Settings menu
2 In the Type Properties dialog, select the dimension type you want to work with from the Type
Specify moment symbols
Connection symbols may appear at either end of the symbol of beams/braces. For each brace
and beam, you can specify the symbol that displays for both the moment connection start and
the moment connection end. The value of moment connection start/end can be moment frame,
cantilever moment, or none.
Annotations
list.
page 1032 for property descriptions.
Annotations
list.
See Modifying Text Note Properties
Annotations
list.
Arrowheads.
Text.
on page 1031.
Dimensions, and then a dimension style.
Leader Arrowhead Properties
Annotation Styles | 491
