Name
Estimated Reinforcement Volume
Dimensions
Length
Width
Volume
Elevation at Bottom
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished
Structural Analysis
Analyze As

Isolated Foundations

Isolated foundations are standalone families that are part of the structural foundation category. Several types
of isolated foundations can be loaded from the family library, including pile caps with multiple piles,
rectangular piles, and single piles.
Description
Specifies the estimated reinforcement volume of the selected element. This is a
read-only parameter that only displays when rebar has been placed.
Indicates the overall length. This is a read-only parameter.
Indicates the overall width. This is a read-only parameter.
Indicates the Volume of the foundation. This is a read-only parameter.
Elevation at the bottom of the retaining wall. This is a read-only parameter.
A field for placing general comments about the foundation type.
A label created for the foundation. This value must be unique for each element
in a project. Revit Architecture warns you when the number value is already used
but allows you to continue using it. You can see the warning using the Review
Warnings command. See Reviewing Warning Messages
Indicates in which phase the foundation component was created. See
Phasing on page 1263.
Indicates in which phase the foundation component was demolished. See
Phasing on page 1263.
Indicates the property type for structural analysis. Select either Foundation or
Not for Analysis.
on page 1334.
Project
Project
