Roof Soffit Examples

Soffit selected in elevation view
Soffits selected on model with gambrel roof

Roof Gutters

You can add gutters to edges of roofs, soffits, and fascia. You can also add gutters to model lines.
NOTE The Join Geometry tool was used to join the soffit and the roof in the previous illustration. To
complete the image, use the Join Geometry command to join the soffit to the wall, and the wall to
the roof. See Joining Geometry
TIP Use the Slope Arrow tool to create a sloping soffit. See
on page 334.
Roof Slope Arrow on page 616.
Roof Gutters | 629
