5 To create an additional rail, click Insert. Enter a name for the rail, and the height, offset, profile,
6 Click Up or Down to adjust the railing position.
7 When you are finished, click OK.

Modifying Railing Joins

You can override joins for a railing on a join-by-join basis.
To modify rail joins
1 Open the plan view where the railing is located.
2 Select the railing, and on the Options Bar, click Edit.
3 On the Sketch tab of the Design Bar, click Edit Joins.
4 Place the cursor over a railing join, and click.
5 On the Options Bar, for Rail Join, select a join method.
Join methods are set by the Angled Joins and Tangent Joins parameters for the railing type. For more
information on these parameters and join methods, see

Modifying Railing Height and Slope

You can control the height and slope of individual rail sketch lines. For example, on a set of U-shaped stairs,
you may want to set the inner railing to a different height than the outer railing. With slope adjustment,
you can control how the railing segment follows the slope of the stairs. You may want the segment to be
flat at some points or sloped at other points.
To modify railing height and slope
1 Open the plan view where the railing is located.
2 Select the railing, and on the Options Bar, click Edit.
3 Select a railing sketch line.
4 For Height Correction, select Custom.
5 Enter a value in the text box.
6 For Slope, select one of the following values:
682 | Chapter 11 Working with Architectural Components
and material properties.
NOTE A box appears around the join when you move your cursor over it. When the join is selected,
an X appears on the join.
Note that Height Correction is set to By Type. This indicates that height adjustment is controlled
by the railing type.
The text box adjacent to Height Correction is enabled.
By Host means that the railing segment follows the slope of its host (for example, stairs or
ramps).
Railing Type Properties on page 689.
