Shape Editing for Slabs, Roofs and Floors

You can use shape editing tools to manipulate the surface of either an existing horizontal slab, roof, or floor,
by defining high and low points for drainage. By specifying the elevation of these points, you split the
surface into sub regions that can slope independently.
Description
indicates the elevation used for tagging the Bottom of Foundation. This is a read-
only parameter.
A field for placing general comments about the slab.
A label created for the slab. Possible use: shop mark. This value must be unique
for each element in a project. Revit Architecture warns you when the number
value is already used but allows you to continue using it. You can see the warning
using the Review Warnings command. See
page 1334.
Indicates in which phase the slab component was created. See
on page 1263.
Indicates in which phase the slab component was demolished. See
Phasing on page 1263.
If set to Foundation, the slab will provide support for other elements connected
to it. If set to Slab on Grade, the slab will only support itself.
The plane of the slab used for analysis and design.
Shape Editing for Slabs, Roofs and Floors | 881
