3 In the Options dialog box, under Big Steering Wheel Appearance or Mini Wheel Appearance, select an
option for Opacity.
4 Click OK.
To control the startup placement of the wheels
1 Display a wheel.
2 Right-click on the wheel and click Options.
3 In the SteeringWheels Options dialog box, under Steering Wheel Visibility, click Always Show the
Pinned Wheel on Startup.
4 Click OK.
To enable tooltips for wheels
1 Display a wheel.
2 Right-click on the wheel and click Options.
3 In the SteeringWheels Options dialog box, under Steering Wheel Visibility, click Show Tooltips.
Tooltips are displayed for the wedges and buttons on a wheel when the cursor hovers over the wheel.
4 Click OK.
To enable messages for wheels
1 Display a wheel.
2 Right-click on the wheel and click Options.
3 In the SteeringWheels Options dialog box, under Steering Wheel Visibility, click Show Tool Messages.
Messages are displayed when you use the navigation tools.
4 Click OK.

Wheel Menu

From the Wheel menu, you can switch between different wheels.
Use the Wheel menu to switch between the big and mini wheels that are available, go to the Home view,
change the preferences of the current wheel, and control the behavior of the orbit, look, and walk 3D
navigation tools. The menu items available on the Wheel menu are dependent on the current wheel.
The Wheel menu has the following options:
Mini View Object Wheel. Displays the mini version of the View Object wheel.
Mini Tour Building Wheel. Displays the mini version of the Tour Building wheel.
Mini Full Navigation Wheel. Displays the mini version of the Full Navigation wheel.
Full Navigation Wheel. Displays the big version of the Full Navigation wheel.
Basic Wheels. Displays either the big version of the View Object or Tour Building wheel.
Go Home. Goes to the Home view saved with the model.
Fit to Window. Resizes and centers the current view to display all objects.
178 | Chapter 4 Project Views
