Foundation Slab Properties

You can specify the Structural Usage parameter of a Foundation slab: either Foundation or Slab on Grade.
If set to Foundation, the slab will provide support for other elements connected to it. If set to Slab on Grade,
the slab will only support itself. The Foundation Slab Type also has an additional, read-only parameter,
Elevation at Bottom. The Elevation at Bottom parameter is used for tagging the Bottom of the Foundation
elevation. You can modify parameter names, values, and descriptions for Foundation Slabs.
See Foundation Slabs
Foundation Slab Type Properties
Name
Construction
Structure
Thickness
Graphics
Coarse Scale Fill Pattern
Coarse Scale Fill Color
Identity Data
Keynote
Model
Manufacturer
Type Comments
URL
Description
Assembly Description
Assembly Code
Type Mark
on page 878.
Description
Select the Edit button to add, change, or delete slab layers.
Slab thickness. This is a read-only parameter.
Specifies a fill pattern for a slab in coarse-scale view. Click in the value box to
open the Fill Patterns dialog. See
Applies a color to the fill pattern for a slab in a coarse-scale view.
Add or edit the slab keynote. Click in the value box to open the s dialog. See
Keynotes on page 1058.
The manufacturer internal number.
The slab manufacturer.
A field for placing general comments about the slab type. This information can
be included in a schedule.
A link to a web page that may contain type specific information.
Enter or edit the description of the slab.
Describes the assembly based on the assembly code selection. This is a read-only
parameter.
A uniformat assembly code selected from a hierarchical list.
A value that designates the specific slab. This value must be unique for each
element in a project. Revit Architecture warns you when the number value is
View Properties on page 210.
Foundation Slab Properties | 879
