4 Click OK.
Door Type Properties
Name
Construction
Wall Closure
Construction Type
Materials and Finishes
Door Material
Frame Material
Dimensions
Thickness
Height
Trim Projection Ext
Trim Projection Int
Trim Width
Width
Rough Width
Rough Height
Identity Data
Keynote
Model
Manufacturer
Type Comments
Description
The layer wrapping around the door. It overrides any settings in the host.
The type of construction for the door.
The material for the door (for example, metal or wood)
The material for the door frame.
The thickness of the door.
The height of the door.
The exterior trim projection.
The interior trim projection.
The width of the door trim.
The width of the door.
Can be scheduled or exported.
Can be scheduled or exported.
Add or edit the door keynote. Click in the value box to open the Keynotes dialog.
See
Keynotes
on page 1058.
The name of the model type of the door.
The name of the door manufacturer.
Comments about the door type. Information can appear in a schedule.
Doors | 735
