Removing Graphic Display Overrides For Element Categories - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

2 Right-click an element in the drawing area, and click Override Graphics in View
3 If necessary, click the appropriate tab in the Visibility/Graphics dialog (Model Categories,
4 Highlight a category row.
5 Click the Override button for the line or pattern to edit.
6 For lines, edit the line weight, line color, and line pattern. For patterns, edit the fill color and
7 Select the Halftone check box next to a category to blend the line color of an element about 50
8 For model categories, you can also override the detail level.
9 Click Apply to view your changes, and click OK to exit the Visibility/Graphics dialog.

Removing Graphic Display Overrides for Element Categories

1 Open the view in which you want to remove graphic overrides.
2 Right-click an element in the drawing area, and click Override Graphics in View
When you use this method, the element s category is already highlighted when the
Visibility/Graphics dialog opens.
Alternatively, you can click View menu
or VV.
NOTE If you open the Visibility/Graphics dialog from a drafting view, only those categories that can
appear in a drafting view display.
Annotation Categories, or Imported Categories).
If you are overriding element categories in a linked Revit model:
a Click the Revit Links tab.
b Click the button in the Display Settings column.
c In the RVT Link Display Settings dialog, click Custom.
d Click the appropriate tab (Model Categories, Annotation Categories, or Imported Categories).
e Select Custom from the drop-down menu.
NOTE For annotation and imported categories, you can only override projection and surface display.
fill pattern.
percent with the background color of the view. This produces a lighter shade for the line color.
For Detail Level, select a detail level at which to display the element category. This overrides
the detail level of the view. For example, you can set a wall to display at medium or fine detail
level to see its structure, even if the view detail level is set to coarse.
You cannot set the detail level for subcategories. They inherit it from their parent category.
When you use this method, the element s category is already highlighted when the
Visibility/Graphics dialog opens.
Alternatively, you can click View menu
or VV.
NOTE If you open the Visibility/Graphics dialog from a drafting view, only those categories that can
appear in a drafting view display.
Removing Graphic Display Overrides for Element Categories | 153
Visibility/Graphics, or use the keyboard shortcut VG
Visibility/Graphics, or use the keyboard shortcut VG
By Category.
By Category.
