Name
Base Offset
Base Is Attached
Base Extension Distance
Top Constraint
Unconnected Height
Top Offset
Top is Attached
Top Extension Distance
Room Bounding
Floor Attachment
Related to Mass
Structural
Structural Usage
Dimensions
Length
Area
Volume
Identity Data
Comments
Description
The wall's height from its base constraint. This property is available only when the
Base Constraint is set to a level.
Indicates whether the base of the wall is attached to another model component,
such as a floor. This is a read-only value.
The distance you have moved the base of the layers in a wall. See
Structure on page 748. This parameter is enabled when layers of a wall are extendable.
Wall height extends to value specified in Unconnected Height.
The height of the wall when it is sketched.
The offset of the wall from the top level. This parameter is enabled only when the
Top Constraint is set to a level.
Indicates whether the wall top is attached to another model component, such as a
roof or ceiling. This is a read-only value.
The distance you have moved the top of the layers in a wall. See
on page 748. This parameter is enabled when layers of a wall are extendable.
If selected, the wall is part of a room boundary. If cleared, the wall is not part of a
room boundary. This property is read-only before creating a wall. After you draw
the wall, you can select it and then modify this property.
The layer to which the floor is attached.
Indicates that the element was created from a mass element. This is a read-only
value.
The structural usage of the wall. This property is read-only before creating a wall.
After you draw the wall, you can select it and then modify this property.
The length of the wall. This is a read-only value.
The area of the wall. This is a read-only value.
The volume of the wall. This is a read-only value.
Specific comments added to describe the wall.
Compound
Compound Structure
Wall Properties | 605
