4 Drag the camera to move it. The view updates according to the new camera position.
5 Drag the target to move it. The view updates according to the new target point.
6 Select the perspective view. Drag the handles to vary the field of view (FOV).

Turning Off the Camera in a 3D View

Turning off the camera in a 3D view is the same as showing or hiding the crop region. See
Crop Regions
To turn off the camera in any other view type, click a blank area in the drawing area.

3D View Properties

Parameter names, values, and descriptions for 3D views.
Name
Graphics
View Scale
Scale Value
Detail level
Visibility/Graphics Overrides
Model Graphics Style
Advanced Model Graphics Style
Discipline
Identity Data
View Name
Title on Sheet
Default View Template
Extents
on page 165.
Description
The scale of the 3D view.
A ratio derived from the view scale. For example, if your view scale is 1:100, the
scale value is the ratio of 100/1 or 100. If you select a value of Custom for the view
scale, you can enter a ratio in the value field for this property.
Applies the detail level setting to the view: coarse, medium, or fine.
Opens the Visibility/Graphics dialog, where you can set visibility options for the
view.
Changes the display to Hidden Line, Wireframe, Shading, or Shading with Edges.
Click Edit to access Advanced Model Graphics, which controls shadows and silhouette
lines.
Select the discipline for the view from the list. Select Structural to hide non-load-
bearing walls from the view.
A name you define for the 3D view.
The name of the view as it appears on the sheet; it supersedes any value in the View
Name property.
Identifies the default view template for the view. See View Templates
Turning Off the Camera in a 3D View | 115
Showing or Hiding
on page 498.
