Opening a Callout View

To open a callout view, use any of the following methods:
In the Project Browser, double-click the name of the callout view.
In the parent view, double-click the callout head.
In the parent view, right-click the callout head, and click Go to View.

Modifying a Callout

After creating a callout, you can change it in the following ways.
If you want to...
change the type of callout tag assigned to a callout
enlarge or reduce the area shown in a callout view
change the format of the callout head, or the information
that it displays
For a callout bubble:
change the line color, weight, or style
change the radius of the corners
For the leader line:
change the line color, weight, or style
change the location of the leader line

Changing the Callout Tag Family for a Callout

The callout tag consists of the callout head, callout bubble, and leader line. (See
99.) You define the style of the callout head and the radius of the corners of the callout bubble in a callout
tag family. (See
callout, use the following procedure.
NOTE Define the line weight, color, and style for the callout bubble and the leader line in the project. See
Display Properties for Callout Tags
102 | Chapter 4 Project Views
Creating a Callout Tag Family
on page 106.
then
see Changing the Callout Tag Family for a Callout
102.
see Changing the Boundaries of a Callout
see Creating a Callout Head
see Changing Display Properties for Callout Tags
106.
see Creating a Callout Tag Family
see Changing Display Properties for Callout Tags
106.
see Adjusting the Callout Leader Line
on page 106.) To assign a callout tag family to an existing
on page
on page 103.
on page 104.
on page
on page 106.
on page
on page 103.
Callout Tag Parts on page
Changing
