5 Click OK twice.
Creating a Grid Line with a Center Segment
1 Open a view that displays grid lines.
2 Select a grid line, and click
3 In the Element Properties dialog, click Edit/New.
4 In the Type Properties dialog, do the following:
5 Click OK twice.

Grid Properties

You can change properties for individual grid lines or for grid types.

Modifying Grid Properties

1 In a project view, select a grid line and click
2 In the Element Properties dialog, edit instance properties.
3 To edit type properties, click Edit/New.
4 Click OK.
Use the other parameters to indicate which grid bubble to use and where it should display.
See Grid Type Properties
Revit Architecture updates all grid lines of this type in all views.
For Center Segment, select Custom.
For Center Segment Weight, Center Segment Color, and Center Segment Pattern, specify
the line weight, color, and pattern of the center segment of the grid line.
For End Segment Weight, End Segment Color, and End Segment Pattern, specify the line
weight, color, and pattern of the end segments of the grid line.
For End Segments Length, enter the length of the segments (in paper space) to display on
each end of the grid line.
Use the other parameters to indicate which grid bubble to use and where it should display.
See Grid Type Properties
Revit Architecture updates all grid lines of this type in all views.
See Grid Instance Properties
See Grid Type Properties
that type in the project. You can click Duplicate to create a new grid line type.
on page 1040.
(Element Properties).
on page 1040.
on page 1041.
on page 1040. Changes made to type properties affect all grid lines of
.
Grid Properties | 1039
