Name
Description
Assembly description
Assembly code
Type Mark
Cost

Roof Fascia and Gutter Instance Properties

Name
Constraints
Vertical profile offset
Horizontal profile offset
Angle
Dimensions
Length
Identity Data
Comments
Mark
640 | Chapter 11 Working with Architectural Components
Description
Description of the fascia or gutter.
Description of the assembly, based on the assembly code selection.
Uniformat assembly code selected from hierarchical list.
A value to designate the particular fascia or gutter. This value must be unique for
each fascia or gutter in a project. Revit Architecture issues a warning if the number
is already used but allows you to continue using it. You can see the warning using
the Review Warnings command. See
Cost of the fascia or gutter. Can be included in a schedule.
Description
Moves the fascia or gutter above or below the edge on which you created it. For
example, if you chose a horizontal roof edge, a fascia moves above or below that
edge.
Moves the fascia or gutter forward or backward from the edge on which you created
it.
Rotates the fascia or gutter to the desired angle.
The actual length of the fascia or gutter.
Comments about the roof fascia or gutter.
A label applied to roof fascia or gutters. Usually a numeric value. This value must be
unique for each roof fascia or gutter in a project. Revit Architecture issues a warning
if the number is already used but allows you to continue using it. You can see the
warning using the Review Warnings command. See
on page 1334.
Reviewing Warning Messages
Reviewing Warning Messages
on page 1334.
