Creating an Array

The elements of an array can follow a line (a linear array), or they can follow an arc (a radial array). When
creating an array, you specify the distance between elements using either of the following methods:
Specify the distance between the first and second elements. (Use the Move To 2nd option.) All subsequent
elements use the same spacing.
Specify the distance between the first and last elements. (Use the Move To Last option.) All remaining
elements are evenly spaced between them.
A linear array
A radial array

Creating a Linear Array

1 Select one or more elements to be copied in an array.
2 Click Edit menu
3 On the Options Bar, click
Array, or click on the Edit toolbar.
(Linear).
Creating an Array | 295
