Adding an Image to a Sheet

1 Prepare the image file.
2 In the Revit project, open the sheet.
3 Click File menu
4 In the Open dialog, navigate to the location of the image file.
5 Select the image file, and click Open.
6 Click in the drawing area to place the image on the sheet.
To reposition the image, drag it to the desired location on the sheet. To resize the image, select it, and drag
a blue corner dot.

Sheet Properties

Use sheet properties to control the appearance and behavior of a sheet. For example, you can specify the
sheet name and number, and whether the sheet is included in the drawing list. You can also use sheet
properties to define information that displays on the sheet, such as the issue date, designer, and reviewer.
NOTE To track printing times, Revit Architecture displays a date and time stamp on sheets. To format the display
of this stamp, modify the regional and language settings on your computer.

Modifying Sheet Properties

To modify sheet properties, do either of the following:
In the Project Browser, right-click the sheet name, and click Properties.
Open the sheet. Right-click in the drawing area, and click View Properties.
You can modify the properties of multiple sheets in one operation. For example, you can change the Sheet
Issue Date for several sheets in one step. In the Project Browser, use CTRL+click to select non-adjacent sheet
names, or SHIFT+click to select adjacent sheet names. Then right-click, and click Properties. When you use
this method, changes that you make to the view properties affect all selected sheets.

Sheet Instance Properties

Name
Visibility/Graphics
Overrides
Revit Architecture supports the following image file types: BMP (bitmap), GIF, JPEG, JPG, PNG
(portable network graphics), and TIFF.
Import/Link
NOTE If the legacy details are stored using a CAD format, such as DWG, use File
menu Import/Link CAD Formats.
Description
Click Edit to display the Visibility/Graphics Overrides dialog for the sheet. See
Display in Project Views
Image.
on page 150.
Visibility and Graphic
