5 On the Element Properties dialog, click OK.
6 Open the sheet to see the results.

Splitting a Schedule on a Sheet

When you place a schedule on a sheet, you can split the schedule into 2 or more sections to fit the space
on the sheet.
NOTE You cannot split a schedule across multiple sheets.
The following procedure assumes that you have added a sheet to a project and placed a schedule on the
sheet. See Adding a Sheet
To split a schedule on a sheet
1 Open the sheet.
2 Select the schedule on the sheet.
3 Click the Z break control.
4 To split a section of the schedule further, click the Z break control again.
5 To adjust the number of rows in a section of the schedule, drag the blue dot at the bottom of
on page 970 and
Blue controls allow you to move and manipulate the schedule. The Z break control in the middle
of the right border splits the schedule.
The schedule divides into 2 sections, splitting at the approximate location of the Z break control.
NOTE You cannot delete schedule sections from a sheet. You cannot drag schedule sections from
one sheet to another.
the first section.
If you shrink the schedule section, rows that do not fit automatically move to the next section.
The last section contains the remaining rows, so you cannot resize it.
Adding a Schedule to a Sheet
Splitting a Schedule on a Sheet | 1003
on page 1002.
