Room Boundaries in Linked Models

When you link Revit models together, by default Revit Architecture does not recognize room-bounding
elements in the linked model. If you try to place a room between walls in the host project and walls (or
other elements) in a linked model, Revit Architecture does not automatically recognize the room-bounding
elements of the linked model. However, you can force Revit Architecture to recognize the room-bounding
elements of a linked model. See
Placing rooms in a host project (building exterior) using walls in a linked model
(building interior)
More about rooms and linked models
If you unload a linked model, rooms in the host project are no longer bounded by the room-bounding
elements in the linked model.
Elements in a nested link are room-bounding when you turn on the Room Bounding parameter of the
nested linked model and the Room Bounding parameter of its parent model.
Related topics
Working with Linked Models
Room-Bounding Elements
Using Room Boundaries in a Linked Model
Use the following procedure to make the host project recognize the Room Bounding parameter of elements
in the linked model.
To use room boundaries in a linked model
1 In a plan view of the host project, select the linked model symbol.
920 | Chapter 14 Rooms and Areas
Using Room Boundaries in a Linked Model
on page 1213
on page 917
The status bar displays the following:
RVT Links : Linked Revit Model : <model name>.
on page 920.
