Second Point or Whole Line Snapping Only
Horizontal or Vertical snap—When sketching a straight line, Revit Architecture snaps the line to be perfectly
horizontal or vertical when the cursor approaches horizontal or vertical.
Horizontal snap
Vertical snap
Snap Parallel to Existing Line—Snaps a line parallel to existing geometry.
Snap Perpendicular to Existing Line—Snaps a line perpendicular to existing geometry.
TIP The status bar indicates the snap points when you move the cursor.

Object Snaps and Snap Shortcut Key Combinations

The following table defines the object snaps listed in the Snaps dialog (Settings menu
shortcut key combinations for these objects. Shortcut key combinations override snap settings for one pick.
Object Snap
Endpoints
496 | Chapter 9 Customizing Project Settings
Shortcut Key Description
SE Snaps to the endpoint of an element or component.
Snaps) and the
