Sweep Properties

Name
Visible
Visibility/Graphics Overrides
Subcategory
Material
Solid/Void
Profile
Horizontal profile offset
Vertical profile offset
Angle

Swept Blend Properties

Name
Visible
Visibility/Graphics Overrides
Subcategory
Material
Solid/Void
Description
Sets whether the sweep is visible in a project. If the check box is selected, the sweep is
visible. If the check box is cleared, the sweep is not visible.
Overrides the visibility and graphics settings of the sweep family in the project.
Sets the geometry as a subcategory to a family category. See
page 395. The default is None.
A material for the surface of the family for rendering purposes.
Switches solid geometry from a cut to a solid. This switch is effective if you create a
complex geometry cut and want to copy the shape of that cut and change it to a solid.
For example, if you cut a complex sweep out of an extrusion, you might want to copy
that sweep shape and use it as a solid.
Sets the profile family for the sweep. Values depend on which profile families are loaded
in the project. See Profile Families
Horizontal offset value for profile.
Vertical offset value for profile.
Rotation angle for profile, in degrees.
Description
Sets whether the swept blend is visible in a project. If the check box is selected, the swept
blend is visible. If the check box is cleared, the swept blend is not visible.
Overrides the visibility and graphics settings of the swept blend family in the project.
Sets the geometry as a subcategory to a family category. See
page 395. The default is None.
A material for the surface of the family for rendering purposes.
Switches solid geometry from a cut to a solid. This switch is effective if you create a
complex geometry cut and want to copy the shape of that cut and change it to a solid.
For example, if you cut a complex sweep out of an extrusion, you might want to copy
that sweep shape and use it as a solid.
Creating a Subcategory
on page 371.
Creating a Subcategory
Family Geometry Properties | 397
