3 Click in the drawing area to place the column.
TIP Typically, you align columns when placing them by selecting a grid line or wall. If you randomly placed them
and you want to align them, click Edit menu
are 2 perpendicular reference planes that you can select for alignment.

Attaching Columns

Columns do not automatically attach to roofs, floors, and ceilings. When you select a column (or multiple
columns) you can attach it to roofs, floors, ceilings, reference planes, structural framing members, and other
reference levels using the Attach and Detach buttons on the Options Bar. When you select one or more
columns, the Attach and Detach buttons appear on the Options Bar. From the Options Bar you can attach
the Top or Base of a column (or columns) and set the Attachment Style (Cut Column, Cut Target, Do Not
Cut), Attachment Justification (Minimum Intersection, Intersect Column Midline, and Maximum Intersection),
and Offset from Attachment. Offset from Attachment sets a value to be offset from the target.
The target (roofs, floors, ceilings) can be cut by the column, the column can be cut by the target, or neither
can be cut. After a column is attached to a target, you can edit its properties and reset the values for the
Instance Parameters Attachment Justification at Top and Offset from Attachment at Top.
NOTE If the column and target are both structural concrete, they will be cleaned instead of cut. If the column is
structural and the target is non-structural, a warning message appears.

Cut Column Examples

Following are examples of the cut column attachment style with different attachment justifications and
offsets from attachment.
Attachment Style: Cut Column
Attachment Justification: Minimum Intersection
692 | Chapter 11 Working with Architectural Components
NOTE You can also change the room-bounding property of a column after placement. See
Architectural Column Properties on page 698.
Align, and select the columns to align. In the middle of the columns
