14 Sketch the repeating detail component in the family by clicking once for a start point, dragging

Detailing Tools

Callouts: Create a callout first to get a close-up view of a plan or elevation view. All detail annotations
are added to the callout view. See
Detail Lines: Use detail lines to add information or sketch over existing elements. See
page 1094.
Dimensions: Apply specific dimensions to the detail. See
Text Notes: Use text notes to specify construction methods. See
Detail Components: Create and load custom detail components to place in the detail. Detail components
might be actual construction components, such as structural steel, jambs, or metal studs. See
Detail Component Family
Symbols: Place a symbol, such as a direction arrow or a break mark symbol to indicate omitted information.
See Symbols
Masking Region: Create masking regions to obscure elements in a view. See
1087.
Filled Region: Create detail filled regions and give them a fill pattern to represent various surfaces,
including concrete or compacted earth. You draw regions on the default work plane. It is not necessary
to select a work plane for them. You can apply a fill pattern to the region by selecting the region lines
and clicking Properties. Set a value for the Fill Pattern property. The different fill patterns are defined by
the Fill Patterns command. See
Insulation: Place insulation in a wall detail that shows all the material for the wall. For example, an
exterior wall might include a layer of gypsum, insulation, metal studs, sheathing, air space, and brick.
See Insulation
1086 | Chapter 16 Annotating and Detailing
the mouse, and clicking again for an end point.
The following image shows the addition of a welded wire fabric family to a concrete slab in
section view.
The following image shows a repeating pattern placed between 2 walls. The pattern has a fixed
number of 10 and a length of 6 feet.
on page 1083.
on page 1071.
Filled Region
on page 1073.
Callout Views on page 98.
Placing Permanent Dimensions
on page 1093 and
Detail Lines
Text Notes on page 1027.
Masking Regions
Fill Patterns on page 449.
on
on page 215.
Creating a
on page
