Name
Dimension Line Snap Distance
Text
Width Factor
Underline
Italic
Bold
Text Size
Text Offset
Read Convention
Text Font
Text Background
Units Format
Show Opening Height
Other
Center Marks
Center Mark Size
Radius Prefix
240 | Chapter 5 Using Dimensions and Constraints
Description
To use this parameter, set the Witness Line Control parameter to Fixed to Dimension
Line. With these parameters set, additional snapping is available that aids in stacking
linear dimensions at even intervals. This value should be greater than the distance
between the text and the dimension line, plus the height of the text.
Specify a ratio to define the elongation of the text string. A value of 1.0 has no
elongation.
Underlines the permanent dimension value and text.
Applies italic formatting to the permanent dimension value and text.
Applies bold formatting to the permanent dimension value and text.
Specify the size of the typeface for the dimension.
Specify the offset of the text from the dimension line.
Specify the read convention for the dimension text.
®
Sets the Microsoft True Type fonts for the dimensions.
If you set the value to opaque, the dimension text is surrounded by a box that
overlaps any geometry or text behind it in the view. If you set the value to transpar-
ent, the box disappears and everything not overlapped by the dimension text is
visible.
Click the button to open the Format dialog. You can then set the format of the units
with the dimension. See Setting Project Units
Place a dimension whose witness lines reference the same insert (window, door, or
opening) in a plan view. If you select this parameter, the dimension includes a label
that shows the height of the opening for the instance. The value appears below the
dimension value you initially placed.
Shows or hides the radial dimension center mark.
Sets the size of the radial dimension center mark. This property is enabled when
Center Marks is selected.
Shows or hides prefix (R) for radial dimensions.
on page 492.
