Managing Views

The following topics describe different ways to manage project views to simplify your workflow and help
to manage your building project.

Customizing Project View Organization in the Project Browser

You can sort views and sheets in the Project Browser using any of the property values for the view or sheet.
For example, the following image shows views in the Project Browser organized by discipline, then by phase,
and then by view type. The top level of the Views branch also shows the name of the sort group currently
applied (in this case, Discipline).
In addition to sorting views, you can also limit the views that display in the Project Browser by applying a
filter. This is useful when you have a project with a large number of views or sheets, and you only want to
view a specific set in the Project Browser.
The properties that you can choose from when creating a sort group or applying a filter to the Project Browser
include project parameters and shared parameters. For more information about project and shared parameters,
see Project Parameters
By default, the Project Browser displays all views (by view type) and all sheets (by sheet number and sheet
name).

Sorting Views or Sheets in the Project Browser

1 Click Settings menu
2 In the Browser Organization dialog, click the Views tab to apply a sort to project views, or click
3 Select a sort group.
4 Click Apply, then click OK.
206 | Chapter 4 Project Views
on page 447.
Browser Organization.
the Sheets tab to apply a sort to sheets.
To view the properties of an existing sort group, select it and click Edit.
For information on creating a sort group or editing an existing sort group, see
Browser Sort Group on page 207 and Editing a Project Browser Sort Group
Creating a Project
on page 207.
