Wall Instance Properties - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Graphics
Coarse Scale Fill Pattern
Coarse Scale Fill Color
Identity Data
Model
Manufacturer
Type Comments
URL
Description
Assembly Description
Assembly Code
Type Mark
Fire Rating
Cost

Wall Instance Properties

Name
Constraints
Location Line
Location Line Offset (for walls used as
panels only)
Base Constraint
604 | Chapter 11 Working with Architectural Components
Description
Sets a fill pattern for a wall in a coarse-scale view. See
Applies a color to the fill pattern for a wall in a coarse-scale view.
Generally, this is not an applicable property for walls.
Generally, this is not an applicable property for walls.
A field for placing general comments about the wall type.
Link to a web page.
Description of the wall.
Description of the assembly based on the assembly code selection.
Uniformat assembly code selected from hierarchical list.
A value to designate the particular wall. Generally, this is not an applicable property
for walls. This value must be unique for each wall in a project. Revit Architecture
warns you if the number is already used but allows you to continue using it. You
can see the warning using the Review Warnings command. See
Messages on page 1334.
Fire rating of the wall.
Cost of the materials for constructing the wall.
Description
A location line for the wall at the specified plane. The wall location line remains the
same for that wall, even if the type changes.
Offsets the wall panel the specified distance and in a direction perpendicular to the
face of the curtain wall.
The base level of the wall. For example, Level 1.
View Properties on page 210.
Reviewing Warning
