Roof Slope Arrow Properties

Name
Constraints
Specify
Level at Tail
Height Offset at Tail
Level at Head
Height Offset at Head
Dimensions
Slope
Length

Floors

You create floors by sketching them, either by picking walls or by using the Lines command. Typically, you
sketch a floor in a plan view, although you can use a 3D view if the work plane of the 3D view is set to the
work plane of a plan view. Floors are offset downward from the level on which they are sketched.
In a conceptual design, you can use floor area faces to analyze masses, and create floors from a mass. For
more information, see
on page 546.
Description
Choose between Slope or Height at Tail. If you select Slope, you can enter a value
for Slope. If you select Height at Tail, Level at Head and Height Offset at Head are
enabled.
Specifies the level for the tail relative to the base level of the roof.
Specifies the start height above the Level at Tail.
Specifies the level for the head relative to the base level of the roof. This property is
enabled when Height at Tail is set as the value for Specify.
Specifies the end height above the Level at Head. This property is enabled when
Height at Tail is set as the value for Specify.
Sets a slope value.
The actual length of the slope arrow. This is a read-only value.
Analyzing a Conceptual Design on page 522 and Creating Floors from Mass Instances
Floors | 641
