3 If desired, click Rename to rename the type, or click Duplicate to create a new dimension type.
4 Specify the dimension display properties. See

Loading Tag Styles

1 Click Settings menu
2 Click Load.
3 Navigate to the location of the tag, and open the tag. You can select multiple tag files by holding
4 When you are finished loading tags, click OK.

Specifying the Default Tag for an Element Category

1 Click Settings menu
2 In the Tags dialog, click in the Value column for an element category, and then select a tag

Project Units

You can specify the display format of various quantities in a project. What you specify affects the look of
quantities on the screen and in a printout. You can format data for informational or presentation purposes.
Project units are grouped by discipline, such as common, structural, or electrical. When you change the
discipline, different unit types are available. In the Project Units dialog, each unit type has a preview of the
display format. For example, length might have a display format of 1' 5 1/2".
NOTE The actual display of editable values that affect the size of the model may be different. For example, you
might specify the display of dimensions to round to the nearest 1 inch; however, if you edit a dimension value in
the drawing area, it may show a value that has fractional inches.

Setting Project Units

1 Click Settings menu
2 In the Project Units dialog, select the discipline.
3 Click the value in the Format column to change the display value for that unit type.
492 | Chapter 9 Customizing Project Settings
descriptions.
Annotations
The Tags dialog displays, listing the different family categories and any associated tags. Depending
on the project template, some element categories may have default tags loaded.
You can load multiple tags for element categories.
either SHIFT or CTRL while selecting. The tag name displays adjacent to the element category.
The last loaded tag for an element category becomes the default tag for that element.
Annotations
name.
NOTE You can also specify the default tag when you use the Load From Library
command to load a tag. This loaded tag becomes the default. See
Project Units, or type the keyboard shortcut UN.
The Format dialog displays.
Dimension Properties
Loaded Tags.
Loaded Tags.
on page 238 for property
Load Family
Loading Families on page 352.
