The 2D Navigation wheel is divided into the following wedges:
Pan on page 187. Repositions the current view by panning.
Zoom on page 191. Adjusts the magnification of the current view.
NOTE Pan and Zoom in a 2D steering wheel pan or zoom the page space. In all other wheels, Pan and Zoom
moves the camera.
Rewind
through previous views.
View Object Wheel
The View Object wheel is for 3D navigation; it includes the orbit 3D navigation tool. Use the View Object
wheel to examine 3D objects from the outside.
The big View Object wheel is divided into the following wedges:
Center
target point used for some of the navigation tools.
Zoom on page 191. Adjusts the magnification of the current view.
Rewind
through previous views.
Orbit on page 186. Rotates the current view around a fixed pivot point.
The mini View Object wheel is divided into the following wedges:
Zoom (Top wedge)
Rewind (Right wedge)
through previous views.
Pan (Bottom wedge)
Orbit (Left wedge)
To switch to the big View Objects wheel
Right-click on the wheel and click Basic Wheels
180 | Chapter 4 Project Views
on page 188. Restores the most recent view orientation. You can move backward or forward
on page 183. Specifies a point on a model to adjust the center of the current view or change the
on page 188. Restores the most recent view orientation. You can move backward or forward
on page 191. Adjusts the magnification of the current view.
on page 188. Restores the most recent view. You can move backward or forward
on page 187. Repositions the current view by panning.
on page 186. Rotates the current view around a fixed pivot point.
View Object Wheel.
