To rehost work plane-based and face-based elements and components
1 Select a work plane-based or face-based element or component.
2 On the Options bar, click Rehost.
3 On the Options bar, select a placement option: Place on Face, Place on Work Plane, or Place on
4 Move the cursor to an appropriate host, and click to place the element or component.

Rehosting Level-based Components

Level-based components include furniture, site components, plumbing supplies, and so on. When you place
a level-based component on a host, it remains on the host's infinite plane. For example, when you place a
desk on a floor, and then drag the desk beyond the confines of the floor, the desk remains on the same plane
as the floor.
If the floor has 2 levels, such as a sunken floor, use this method to move the component from one part of
the floor to another.
Selected component residing on floor host
Component dragged away from floor remains on same plane
NOTE When rehosting level-based components, you may find it useful to work in hidden line mode in an elevation
view.
To rehost level-based components
1 Select a level-based component.
2 On the Options Bar, click Pick Host.
3 Click a floor, surface, or level.

Compound Structure

Walls, floors, ceilings, and roofs can comprise parallel layers. The layers can consist of a single continuous
plane of material (such as plywood) or multiple materials (such as gypsum board, studs, insulation, air spaces,
bricks, and sheathing). In addition, each layer within the component serves a particular purpose. For example,
some layers provide structural support, while others act as thermal barriers. Revit Architecture considers the
function of each layer and matches the layers appropriately.
748 | Chapter 11 Working with Architectural Components
Alternatively, on the Options Bar, click Edit Work Plane. On the Work Plane dialog, click Pick
a New Host. See Sketching and Work Planes
dialog options.
Vertical Face.
See Work Plane-based and Face-based Component Placement Options
of these options.
For example, if you want to move a component from a floor on Level 2 to a floor on Level 5,
select the floor on Level 5. You could also select a level with no floor.
The component is moved to the selected level or floor.
on page 265 for information about other Work Plane
on page 747 for descriptions
