7 In the Constraint list to the right of the Height/Depth selection, specify the constraint of the
8 Click to place the column.
To rotate the column during placement
While placing columns, use the SPACEBAR to change the column rotation before the column is placed. Each
time you press the SPACEBAR, the column rotates to align with the intersecting grids at the selected location.
In the absence of any grids, press the SPACEBAR to rotate the column 90 degrees.
758 | Chapter 12 Working with Structural Components
top or base of the column by Level or select Unconnected.
If you select Unconnected, enter the Height or Depth measurement in the text box to the right
of the Constraint list. This measurement of Unconnected Height/Depth is relative to the current
Level.
Placing a column
Columns snap to existing geometry in Revit. When you place columns at grid intersections,
both grids are highlighted.
Highlighted grids
