3 Clear Use project settings.
4 From the Units menu, select an appropriate unit.
5 From the Rounding menu, select a decimal place value. If you choose Custom from the menu,
6 If applicable, select a Unit suffix from the menu.
7 Select Suppress 0 feet to hide leading zeros on dimensions, such as 0' 6". This option is available
8 Click OK.

Label Type Properties

You can modify the Type Properties of labels.
Name
Graphics
Color
Line weight
Background
Text
Text Font
Text Size
The Use project settings option is selected by default. This means that the value displays according
to the Units setting in the project. See
enter a value in the Rounding increment text box.
only for feet and fractional inches.
Description
Sets the color of the text and the leader line.
Sets the thickness of the line that surrounds the text when you select the text and the
thickness of the leader line. You can change the definition of the line weight numbers
using the Line Weights command in the Settings menu. See Line Weights.
Sets the background for the text note. With Opaque, the background of the note itself
covers material behind it. Transparent allows you to see material behind the note. This
is useful with text notes placed in color-defined rooms.
Sets the Microsoft
Sets the size of the typeface.
Project Units on page 492.
®
True Type fonts for the text note. The default font is Arial.
Label Type Properties | 431
