Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual page 1106

3 Click Drafting menu
4 Specify the elements to tag.
5 Select one or more tag categories.
6 To attach a leader to each tag, do the following:
7 For Orientation, select Horizontal or Vertical.
8 Click OK.
1068 | Chapter 16 Annotating and Detailing
Tag All Not Tagged, or on the Drafting tab of the Design Bar, click Tag
All Not Tagged.
The Tag All Not Tagged dialog displays.
To tag all visible elements in the current view that do not have tags, select All objects in
current view.
To tag only those elements you have selected in the view, select Only selected objects in
current view.
By selecting multiple tag categories, you can tag different types of elements (such as detail items
and generic models) in one operation. To select multiple categories, while pressing SHIFT or
CTRL, select the desired categories.
Under Leader, select Create.
For Length, enter a default leader length.
NOTE If the visibility of the tag category or its object type is turned off, a message displays. Click OK
to allow Revit Architecture to turn on visibility before that category is tagged.
