Specifying Element Category Visibility - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

3 If necessary, click the appropriate tab in the Visibility/Graphics dialog (Model Categories,
4 Highlight a category row or rows.
5 Click the Override button for the line or pattern to edit.
6 Click Clear Overrides.
7 Click Apply to view your changes, and click OK to exit the Visibility/Graphics dialog.
When you remove a graphic display override, the element category displays in the view according to the
settings specified in the Object Styles dialog. For more information, see

Specifying Element Category Visibility

NOTE For information on visibility settings for element categories in linked Revit models and worksets, see
for Linked Revit Models
1 Right-click an element in the drawing area, and click Override Graphics in View
2 Click the Model Categories, Annotation Categories, or Imported Categories tab.
3 To set category visibility, select or clear the check box next to the category or subcategory. If
4 To hide all categories, clear the check box at the top of the tab. For example, to hide all model
5 Click Apply to view your changes, and click OK to exit the Visibility/Graphics dialog.
Controlling Category Selection
Click All to select all rows in the table. If the visibility of all categories is selected, you can clear it for all
categories by clearing one category.
Click None to clear the selection of any selected rows.
154 | Chapter 4 Project Views
Annotation Categories, or Imported Categories).
If you are editing element categories in a linked Revit model:
a Click the Revit Links tab.
b Click the button in the Display Settings column.
c In the RVT Link Display Settings dialog, click Custom.
d Click the appropriate tab (Model Categories, Annotation Categories, or Imported Categories).
e Select Custom from the drop-down menu.
on page 1218 and
When you use this method, the element s category is already highlighted when the
Visibility/Graphics dialog opens.
Alternatively, you can click View menu
or VV.
NOTE If you open the Visibility/Graphics dialog from a drafting view, only those categories that can
appear in a drafting view display.
you clear the check box for a category, all subcategories for that category will not be visible in
the view.
categories, clear the Show model categories in this view check box.
By default, the Visibility/Graphics dialog lists only those element categories that are appropriate
to the particular discipline of Revit you are working with (for example, Revit Architecture). To
list categories from all disciplines, select the Show categories from all disciplines check box.
Controlling Workset Visibility
Visibility/Graphics, or use the keyboard shortcut VG
Object Styles on page 484.
on page 1203.
Visibility
By Category.
