Roof Properties
You can modify several properties for roofs, including slope and structure. You can also modify parameters
for roof boundary lines, roof fascia, and roof gutters.
Modifying Roof Properties
1 If you are in sketch mode, on the Design Bar, click Roof Properties. If you are in a plan view,
2 In the Element Properties dialog, edit roof instance parameters as desired.
3 To edit roof type parameters, click Edit/New. Change the roof type parameters as desired, and
4 Click OK to close the Element Properties dialog.
Following is a completed roof on a model.
select the roof and click
See
Roof Instance Properties
click OK.
See
Roof Type Properties
NOTE Changes made to type parameters affect all roofs of this type in the project. You can click
Duplicate to create a new roof type.
.
on page 637.
on page 636.
Roof Properties | 635
