Structural Column Instance Properties

The following instance properties apply to column families that load during a typical installation. The
properties will vary depending on the column families that are specified during the installation process.
Name
Constraints
Base Level
Base Offset
Top Level
Top Offset
Moves With Grids
Room Bounding
Graphics
Top Connection Symbol
Base Plate Symbol
Materials and Finishes
Column Material
Structural
764 | Chapter 12 Working with Structural Components
Description
A value that designates the particular beam; possibly the shop mark. This value must
be unique for each element in a project. Revit Architecture warns you if the number
is already used but allows you to continue using it. You can see the warning using
the Review Warnings command. For more information, see
Messages on page 1334.
The pricing of the column.
Description
Constraining level of the column base.
Offset of base from base level.
Constraining level of the column top.
Offset of top from top level.
Toggles column constraint to grid. See
Toggles column constraint to room bounding conditions.
Applies to steel columns only. Turns on the visibility of a moment or shear connec-
tion symbol. The symbols are visible only in elevations and cuts parallel to the main
axis of the column in coarse view.
Applies to steel columns only. Turns on the visibility of the base plate symbol. The
symbols are visible only in elevations and cuts parallel to the main axis of the column
in coarse view.
Structural material. For more information, see
on page 480.
Reviewing Warning
Locking Columns to a Grid on page 761.
Material Physical Type Parameters
