5 Specify sorting for the revision schedule, as follows:
a Click the Sorting/Grouping tab of the Revision Properties dialog.
b For Sort by, select Revision Sequence, and specify Ascending or Descending.
c Ensure that Itemize every instance is selected.
6 Specify formatting for column headings in the revision schedule, as follows:
a Click the Formatting tab of the Revision Properties dialog.
b In the Fields list, select a field.
c Specify the heading, orientation, and alignment for the field.
d If you want to omit the selected field from the revision schedule, select Hidden Field.
Use the Hidden Field option, for example, if you want to use the field for sorting or grouping
but do not want it to display in the revision schedule.
Repeat these steps for each field in the revision schedule.
7 Specify display attributes for lines, text fonts, and schedule order and height, as follows:
a Click the Appearance tab of the Revision Properties dialog.
b For Build schedule, specify whether the revision schedule builds from the bottom up or
the top down.
See Building a Revision Schedule from the Top Down or Bottom Up
c For Height, specify whether the height of the revision schedule is user defined (fixed) or
variable.
See Defining the Height of the Revision Schedule
d Use the remaining options of the Appearance tab to define attributes for grid lines, header
text, and body text.
See Formatting a Schedule
8 Click OK.
Revit Architecture creates the revision schedule and displays it in the drawing area.
9 In the Project Browser, double-click the empty node under Sheets (all).
The title block displays in the drawing area.
10 In the Project Browser, under Views (all)
to the drawing area.
11 Place the revision schedule in the desired location on the title block.
To change the width of columns, select the revision schedule, and drag the blue triangles between
column headers.
12 (Optional) To rotate the revision schedule on the title block, see
on page 990.
13 To save the title block, click File menu
click Save.
14 Load the title block into a project.
See Loading a Title Block into a Project
on page 990.
on page 136.
Schedules, select the revision schedule, and drag it
Save, specify a location and file name (if needed), and
on page 987.
Revision Schedules on Title Blocks | 989
on page 991.
Rotating a Revision Schedule
