Sketch the wall
6 Sketch the shape of the wall. If the walls do not appear after you draw them, you may need to
7 Optionally, to edit structural walls. See
8 Optionally, to create arc walls. See

Modifying Structural Walls

You can modify the appearance of structural walls through their properties. You can modify the wall properties
either before or after you place the wall.
Modifying Structural Walls
You modify wall properties, in the Element Properties dialog. To open the dialog, do one of the following:
Select the wall, and then click
On the Structural tab of the Design Bar, click Structural Wall, and then click
Right-click the wall and click Element Properties. The shortcut menu also contains several options for
manipulating the wall, such as changing the zoom scale.
Changing Structural Wall Types
Select a wall in the drawing area, and then select a family type in the Type Selector on the Options Bar.
Creating a structural wall chain
lower the view depth or create a foundation level to use as an underlay for the current level. See
View Range on page 198 and
Lines on page 335.
View Properties on page 210.
Modifying Walls
Arc Walls on page 564.
.
on page 601 and Splitting Walls and
.
Modifying Structural Walls | 841
