Planning sheets with a digital cartoon set

Sheets in Project Templates

When creating a project template, you can include sheets in the template. Start with a blank project file,
and create the standard views and levels that each project should include. Leave the views empty, but assign
standard names to them. To create a standard set of construction documents, create sheets using the desired
title blocks. Add views to the sheets, using the desired viewport templates and view title types. Then save
the empty project as a project template. (See
When you create a project using this project template, all of the views and sheets are already created and
listed in the Project Browser. As you start to draw the building model in the project views, the views on the
sheets update automatically. This technique streamlines the project documentation process and maintains
organizational standards.

Adding a Sheet

1 Open the Revit project.
2 Add a sheet using one of the following methods:
3 Select a title block, as follows:
970 | Chapter 15 Preparing Construction Documents
In the Project Browser, right-click Sheets (all), and click New Sheet.
On the View tab of the Design Bar, click Sheet.
Click View menu New
a In the Select a Titleblock dialog, select a title block from the list.
If the list does not show the desired title block, click Load. In the Library folder, open the
Titleblocks folder, or navigate to the folder where the title block resides. Select the title
block to load, and click Open.
b Click OK.
For information about title blocks, see
Creating a Custom Project Template
Sheet.
Title Blocks on page 984.
on page 437.)
