3 In the Value field for the subcategory property, click once in the box to bring up the arrow for
4 Click OK.
5 In your project, define the display for the family in the Object Styles dialog. See

Families Tips

When creating the sketched geometry, use the reference planes. You can then modify the dimensions
for the reference planes to modify the sketch. The dimensions of the reference plane become properties
of the family and can be used to create other family types of varying sizes.
If there are other dimensions you wish to add to the properties of the family, create a permanent dimension
on the sketch and add a label to the dimension. See

Families Included In The Library

Revit Architecture provides many predefined family types within the library folder.
The families included are
Annotations
Balusters
Casework
Columns
Curtain Wall Panels
Detail Components
Doors
Electrical Fixtures
Entourage
Furniture
Furniture Systems
Lighting Fixtures
Mass
Mechanical Equipment
Planting
Plumbing Fixtures
Profiles
Site
Specialty Equipment
350 | Chapter 8 Creating Your Own Components (Families)
the drop-down menu. Click on the arrow to bring up a listing of the subcategories. Click the
appropriate subcategory.
on page 484.
Dimensioning with Families
Object Styles
on page 359.
