Title Blocks; Title Blocks Overview - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Scale
Dependency
Referencing Sheet
Referencing Detail
Approved By
Designed By
Checked By
Sheet Number
Sheet Name
Sheet Issue Date
Appears in Drawing
List
File Path
Drawn By

Title Blocks

A title block is a template for a sheet. It generally includes a border for the page and information about the
design firm, such as its name, address, and logo. The title block can also display information about the
project, client, and individual sheets, including issue dates and revision information.

Title Blocks Overview

Title blocks define the size and appearance of a drawing sheet. Think of them as templates for the drawing
sheet. You create a title block family using the Family Editor. For each title block, you specify the sheet size
984 | Chapter 15 Preparing Construction Documents
Description
The scale of the views on the sheet. If the sheet contains multiple views displayed at different scales,
this parameter shows the value As indicated.
Indicates whether views on the sheet are dependent on other views. See
Views on page 144.
See the description for Referencing Detail, which follows. From the example, the referencing sheet
is A101.
This value comes from the referencing view that is placed on a sheet. For example, you create a
section in a plan view and place the plan view as the first detail on a sheet numbered A101. The
referencing detail number for the section view is 1. See
and Referencing a Callout View
The person who approved the plans.
The person who designed the plans.
The person who checked the drawing.
A unique identifier for the sheet in the construction document set.
Brief description of the sheet. This name displays in the Project Browser, drawing lists, and other
areas of Revit Architecture.
An issue date for the sheet. This value is separate from the Project Issue Date label contained in the
title block.
Default value is selected. If you clear the check box, the sheet is excluded from drawing lists.
Location of the project file.
The person who drew the plans.
Referencing a Drafting View
on page 1078.
Duplicate Dependent
on page 1082
