Moving Elements with the Move Tool

The Move tool, available on the Edit menu, works similarly to dragging. However, it offers additional
functionality on the Options Bar and allows more precise placement. You can create multiple copies of an
element when you move it.
To move elements with the Move tool:
1 Select the elements to move.
2 Click Edit menu
3 On the Options Bar, click the desired options:
4 Click once to enter a start point for moving.
5 Move the cursor in the direction that you want the element to move.
6 Click again to complete the move, or, for more precision, type a value for the distance to move
Moving 2 walls
302 | Chapter 7 Editing Elements
Move, or click
Constrain: Click Constrain to restrict the movement of the element along vectors that run
perpendicular or collinear to the element.
Disjoin: Click Disjoin to break the association between the selection and other elements
before moving. This option is useful, for example, when you want to move a wall that is
joined to another wall. You can also use the Disjoin option to move a hosted element from
its current host to a new host. For example, you can move a window from one wall to another
wall. This feature works best when you clear the Constrain option.
Copy: Click Copy to move a copy of the element. The original element remains in place.
When you select the Copy option, the Disjoin option becomes selected; you cannot clear it.
Multiple: Click Multiple to create multiple copies of an element every time you click in the
drawing area. The option is available only when the Copy option is selected. See
Elements with the Copy Tool
A preview image of the element appears.
The cursor snaps to snap points. Dimensions appear as guides.
the element and press ENTER.
on the Edit toolbar.
on page 320. (To exit the Multiple Copy function, press ESC.)
Copying
