Name
Comments
Mark
Phasing
Phase Created
Phase Demolished

Ramps

You construct ramps in a manner similar to stairs. For more information on creating shapes and landings,
see Stairs on page 662.
You can create ramps in plan or 3D views.
Finished ramp

Adding a Ramp

1 Click Modelling menu
2 On the Sketch toolbar, click Set Work Plane to select a different work plane. See
3 On the Options Bar, click the straight lines tool or the arc tool (to create a curved ramp).
4 Place the cursor in the drawing area, and drag to sketch the ramp run.
5 Click Finish Sketch.
676 | Chapter 11 Working with Architectural Components
Description
Specific comments on the staircase.
A label created for the stairs. This value must be unique for each stairway in a project.
Revit Architecture warns you if the number is already used but allows you to continue
using it. (You can see the warning using the Review Warnings command. See
viewing Warning Messages
The phase when the stairs were created.
The phase when the stairs were demolished.
Revit Architecture enters sketch mode, and the Run command is active.
Work Planes on page 265.
TIP The default settings for the Top Level and Top Offset properties may make the ramp too long.
Try setting the Top Level to the current level, and the Top Offset to a lower value.
on page 1334.)
Ramp, or on the Modelling tab of the Design Bar, click Ramp.
Re-
Sketching and
