Naming Reference Planes

1 In the drawing area, select a reference plane, and click
2 In the Element Properties dialog, for Name, enter a name for the reference plane.
3 Click OK.

Hiding the Annotation in the View

1 Select one or more annotation lines to hide, and right-click to display the shortcut menu.
2 To hide the selected annotations, click Hide in View
To redisplay the hidden annotation lines, see

Reference Plane Properties

Parameter names and descriptions for reference planes.
To modify reference plane properties, select a reference plane and click

Reference Plane Instance Properties

Name
Construction
Wall Closure
Identity Data
Name
Design Option
Extents
Scope Box
Other
To hide the selected annotations and all other annotations of the same category in the current
view, click Hide in View
Description
The name of the reference plane.
A read-only field that indicates the design option in which the reference plane ap-
pears.
The scope box applied to the reference plane. See
Using Scope Boxes
Category.
Revealing and Unhiding Hidden Elements
on page 1053.
.
Elements.
on page 160.
.
Controlling Visibility of Datums
Naming Reference Planes | 1047
